Halverson HWP-100-3 Point Hitch Firewood Processor

Call for Price
Overview

HWP-100-3 Point Hitch Firewood Processor

Load, cut, and split firewood on the go.

More Freedom. Easier Processing.

Perfect for residential and farm use, the HWP-100-3P is a tractor-mounted, PTO-driven firewood processor. Hook it up to your machine’s power-take-off drive and take it wherever you need.
Specifications
Model
HWP-100-3 Point Hitch
Category Name
Forestry & Fencing
Manufacturer
Halverson
details

Key Features

  • Single-Operator Operation: The HWP-100-3P does three jobs with one machine, enabling a single operator to process more wood in less time.
  • Simple Controls: Lift a log onto the deck, clamp it down with the grab arm, and cut it to length. Once the cut piece falls into place, it’s immediately split by the wedge.
  • On-the-Go Convenience: Take the HWP-100-3P directly to the source – its mobile design allows you to haul the processor to the woods on the back of your machine, eliminating the need to transport heavy logs to a stationary splitter.
  • Quick Attach/Detach Mounting: Effortlessly attach and detach the processor to your tractor, maximizing efficiency and minimizing downtime.
specs
Length 81″ (205 cm)
W/ Hyd. Wedge — 86″ (218 cm)
Width 64″ (162.5 cm)
Height 62 ” (157.5 cm)
Weight 1027 lbs ( 466 kg)
Connections 1-Pressure, 1-Return
Material 3/16″ Steel
Max Log Diameter 14″ (37 cm)
Max Log Length 8′ (2.44 m)
Min Log Length 4′ (1.22 m)
Firewood Cut Length Up to 16″ (33cm – 38 cm)
Saw Bar 18″ (64 cm) Versacut
Saw Chain 68 DL 3/8 pitch 0.58
Saw Motor Gear
Saw Oiler Automatic 2 Qt (1.89 l)
Max Saw Cut 14″ (37 cm)
Splitter Cylinder Custom 3″ x 18″ Stroke
Splitter Force 21,195 @ 2400 psi
Splitting Wedge 2-way or 4-way
In-Feed Sliding Trough Carries Log to Wedge
faq

Frequently Asked Questions

Q: How big of a log can I process?
A: The HWP-100-3P can process logs up to 14” in diameter and 8’ in length.

Q: Where can I purchase one?
A: Get a quote from our sales team or find a dealer near you.

literature
Name Link
Download HWP-100-3P Manual Download
Download HWP-100-3P Flyer Download
Halverson Full Line Flyer Download
Halverson Spec Sheet Download
options
  • The HWP-100-3P comes standard with a 2-way splitting head, but an optional 4-way wedge is available as an upgrade.
  • The HWP-100-3P come standard with a manual adjustable wedge – you can upgrade to a hydraulic adjustable wedge.
  • If your tractor doesn’t have 10 GPM oil flow you can upgrade and add the hydraulic power kit.
