Halverson HWP-100TR-H Firewood Processor
Call for Price
Overview
Specifications
details
specs
faq
literature
options
Documents
HWP-100TR-H Firewood ProcessorLoad, cut, and split firewood on the go.More Freedom. Easier Processing.Perfect for residential and farm use, the HWP-100TR-H is a Honda-powered firewood processor for those who are always on the move. Simply hook it up to a standard 2” ball and take it wherever you need. |
Model
HWP-100TR-H
Category Name
Forestry & Fencing
Year
2024
Sale Type
New
Manufacturer
Halverson
Details
Key Features
- Honda Engine: The HWP-100TR-H features a 22hp Honda engine with an electric start ignition.
- Hydraulic Power: The HWP-100TR-H includes a hydraulic-powered chainsaw and adjustable wedge for cutting and splitting logs. Simply pull the lever and let the processor do the work for you.
- Single-Operator Operation: The HWP-100TR does three jobs with one machine, enabling a single operator to process more wood in less time.
- Simple Controls: Lift a log onto the deck, clamp it down with the grab arm, and cut it to length. Once the cut piece falls into place, it’s immediately split by the wedge.
- On-the-Go Convenience: Take the HWP-100TR directly to the source – its mobile design allows you to trailer the processor to the woods, eliminating the need to transport heavy logs to a stationary splitter.
- Attach/Detach Mounting: Simply hook it up to a standard 2” ball and take it wherever you need. (Not for highway use.)
Specs
| Length | Travel = 126″ (320cm) Working = 96″ (244 cm) |
|---|---|
| Width | 68″ (172 cm) |
| Height | 64″ (162.5 cm) |
| Weight | 1405 lbs (637 kg) |
| Connections | NA |
| Material | 3/16″ Steel |
| Max Log Diameter | 14″ (37 cm) |
| Max Log Length | 8′ (2.44 m) |
| Min Log Length | 4′ (1.22 m) |
| Firewood Cut Length | Up to 16″ (33cm – 38 cm) |
| Saw Bar | 18″ (64 cm) Versacut |
| Saw Chain | 68 DL 3/8 pitch 0.58 |
| Saw Motor | Gear |
| Saw Oiler | Automatic 2 Qt (1.89 l) |
| Max Saw Cut | 14″ (37 cm) |
| Splitter Cylinder | Custom 3.5″ x 18″ Stroke |
| Splitter Force | 21,195 @ 2600 psi |
| Splitting Wedge | 2-way or 4-way |
| In-Feed | Sliding Trough Carries Log to Wedge |
| Tire Size | 4.8-12 |
| Mounting | 2″ Ball |
| Motor | GX630 Honda 20.8 hp 1″ Keyed Shaft |
| Fuel Capacity (Gas) | 1.5 Gal |
| Oil Capacity | 15 Gal |
| RPM | 3600 |
| Pump | Honor Gear Pump 5/8 Keyed Shaft |
| GPM | 16 |
| Hydraulic Filter | Spin On |
FAQ
Frequently Asked Questions
Q: How big of a log can I process?
A: The HWP-100TR-H can process logs up to 14” in diameter and 8’ in length.
Q: Where can I purchase one?
A: Get a quote from our sales team or find a dealer near you.
