Harco Equipment

ID # 18460948

Weaverline Silage Cart

Videos
Call for Price
Overview

Battery power and stainless steel are two well-known features of the Weaverline feed carts. Efficient electric power provides smooth, quiet operation with no toxic fumes. The high-speed discharge and fast apron speeds cut feeding time, unloading the 31-bushel cart of corn silage in 35 seconds. Hydrostatic drive gives you fingertip control of the cart in either forward or reverse. The stainless steel box section and stainless steel augers greatly increase the life of the cart. The all stainless steel conveyor system in the series 5 carts is comprised of the stainless gap-link chain, stainless steel sprockets, and stainless steel slats. The gap-hook chain design allows the slat to be fastened around the side bar of the link, thus avoiding the stress points of other types of attachment. The chain is self-centering on the narrow stainless steel sprockets which results in an extremely easy running, low wear conveyor system. The Weaverline series 5 cart is the best choice for fast, easy feeding and long life.


Specifications
Model
Silage Cart
Category Name
Livestock & Feeding
Manufacturer
Weaverline
models

Weaverline Silage Cart

special models

Special Models

Front and Side Unloading

Drive into a bunk and feed full width out the front as you back out. Flip a lever and convert the cart back to standard side feeding for the barn.

High Discharge Box

13" to 30" discharge height for feeding into high mangers.

Pneumatic Tires

For outside travel, this adds 6-1/2" to the width of the cart.

Hay Special

Specially designed augers and anti-wrap shields allow feeding TMR with dry hay. Material length can be up to 10" long depending on material type.

Options and Kits Available

Extension Side Kit: To increase the capacity of the cart. Made of stainless steel, easy on-easy off. 6" and 12" extensions available.

Corn Baffle Kit: To feed high-moisture corn and other semi-free-flowing materials.

Heavy-Duty Caster Wheel: For rough floors or outside travel.

literature
Name Link
Weaverline Brochure 2022 Download
Series 5 Feed Cart operators manual Download
Series 5 Feed cart parts manual Download
Series 5 optional parts manual Download
Cam Rod Adjustment Download
Connecting Rod Adjustment Download
Series 4 Feed Cart operators manual Download
Series 4 Feed Cart parts manual Download
Series 2 Feed Cart parts manual Download
Series 1 Feed Cart parts manual Download
Videos

Videos

Documents
