The term “multifunctionality” is the most appropriate for the TM hydraulic reach mower series. Thanks to a maximum horizontal reach between 4.5 and 5.5 meters, TM46 and 56 models are widely used both in landscaping and grounds maintenance care. The possibility of combining the reach mowers to tractors of limited power and low weight enables easy operation and friendly use. The TM series includes design features that include drop forged parts for the arms articulation and flail head linkages, spiral rotor with double helix and overlapping knives, pump and cast iron motor and flail head floating system enabling the flail head to better follow the ground contours.
Max horizontal reach: 15'3" Tractor power 50 - 70 HP Min. tractor weight: 5512 lbs Min. tractor width: 5'11" Weight: 1713 lbs Rotor power 35 HP Power of hydraulic system 45 HP Flail head angle 190° Max Cutting width: 1 3/4"
Reliability and simply use. Standard on all machines Classic.
ELECTRA - PROGRESSIVE ELECTRICAL CONTROL
The distributors are actuated by means of a mixed system. The joystick controls the function of the first and second booms, while the head inclination is a electrically controlled via the buttons above the joystick. Rotor movement is carried out via a flexible cable control.
