Stock #  103

Big Jim Five Section Folding Packers

Call for Price
Overview

The Superflex concept has proven to be the most revolutionary design in packers for years. The independent floating design lets each section follow the contour of the soil giving more effective wheel to soil contact. The design also allows each section to independently float over obstacles such as stones without placing excessive weight on the gang causing wheel, shaft or bearing damage.

Construction of the “Magnum Series” allows us to produce 40 to 50 foot packers with 19” wheels and scrapers and still maintain sufficient capacity to incorporate heavier larger diameter wheels in the future should the demand arise.

Available in RedGreenBlue  and Orange frame colours.

Specifications
Model
Five Section Folding Packers
Category Name
Tillage
Manufacturer
Big Jim
standard features
  • Forged Pintle / Clevis Adjustable Hitch
  • 7000lb Tongue Jack
  • Grade 70 20,000 lb 3/8” DOT approved for agricultural use safety chains x 2
  • Tandem 4” x 24” Inner Wing Cylinders
  • Tandem 3 ½” x 24” Outer Wing Cylinders
  • 2 LED Road Light Boxes
  • 14/7 Heavy Jacket Wiring
  • 7 Pin Aluminum Light Plug
        Reflective Tape
All plumbing neatly arranged and tied in place

Rugged 1 ¾” hinge pins, securely fastened

Big Jim Five Section Folding Packers

3 beam outerwing section w/ two cylinders, each packer gang oscillates on centre pin and plastic wear plates

Big Jim Five Section Folding Packers

Adjustable clevis hitch, safety chains, 7000 lb tongue jack, steel hydraulic lines

Big Jim Five Section Folding Packers

5 bearing main frame section, lights & reflectors standard

Big Jim Five Section Folding Packers

Rugged 4 beam main with section with two cylinders

Big Jim Five Section Folding Packers
options
  • 18” Ductile Smooth Sprocket Combination Wheel
  • 19” Ductile Notched Wheel
  • Scrapers for 19” Notched Wheels
  • 20” Ductile Crowfoot Wheels
Ductile Wheels carry a 3 year limited warranty.
specifications
Hubs (4)
6 Bolt 5000 lb
Tires (4)
11L-15 12-Ply
Wheels (4)
6 Bolt Solid Centre
Tongue Material
7” x 5” x 3/8” Wall
Transport Width
16’ 8” (all)
Outer Wing Tubes
6” x 4” x ¼” Wall
Transport Height
15’ (50’ Model)
Wheel Gang Tubes
6” x 4” x ¼” Wall
Gang Shaft Bearings
1 ¾” NTN Triple Seal
Hydraulic Cylinders
3000 PSI (CDN Made)
Main Frame Material
6” x 6” x 3/8” Wall
Hydraulic Connections
JIC and ORB
Tongue Brace Material
3” x 3” x ¼” Wall
Inner Wing Rear Tubes (2)
6” x 4” x ¼” Wall
Inner Wing Front Tubes (2)
6” x 4” x 3/8” Wall
Pivot Pins And Gang Shafts
1 ¾” C.R. (C1045)
Drawbar Weight (Transport Position)
1100 lbs (46’ Model)
Total Weight (46’ W/ 19” Wheels)
~15058 lbs
